Page 16 of 20 75.0034.03 ULTIMO 20220120
OUTPUTS & DIAGNOSTICS SETTINGS
Out1Funct off RAD or IR RAD Out1Logic N.O. N.C. Out1HoldTime 0.5 sec 1 sec 2 sec 3 sec 4 sec 5 sec 6 sec 7 sec 8 sec 9 sec Out2Logic N.O. N.C. Out2HoldTime 0.5 sec 1 sec 2 sec 3 sec 4 sec 5 sec 6 sec 7 sec 8 sec 9 sec InTestLogic Active High Active Low InTestMode
1
off on auto
Admin menu see next page Error log last 10 errors + day indication IR:Synch status of IR synchronization IR:Spotview view of spot(s) that trigger detection IR:C1 Energ. signal amplitude received on curtain 1 IR:C2 Energ. signal amplitude received on curtain 2 IR:C3 Energ. signal amplitude received on curtain 3 IR:ReactTime reactivity speed of infrared in relation to immunity and environment PowerSupply supply voltage at power connector Reset log no yes FactoryRst
2
full partial
SETTINGS (cont.)
NOTES:
1. The sensor LED will briefly flash RED during monitoring communication with the door control. This indicates that external monitoring is functional. Monitoring functionality must be active on the sensor
and door control, and monitoring wires must be properly connected to the door control.
2. Partial reset is only available via remote control. Partial restores all adjustable settings except Out1Logic and Out2Logic.
