33
Controller operation
Main Menu
5.2.3.1.1 DISPLY SETUP
The DISPLY SETUP (DISPLAY SETUP) parameter contains the language selection,
decimal separator, and keypad sound parameters.
5.2.3.1.1.1 LANGUAGE
The LANGUAGE parameter is used to set the display language. Use the right or left
arrow key to select the preferred language and press “ENTER” to accept the selection.
The user needs to exit from the SYSTEM MENU window in order for the change in
language selection to take affect.
NOTE: If the wrong language is selected, return to the Main Screen by holding
EXIT for a few seconds. Once the Main Screen is displayed, simultaneously
press and hold F1 and F4 to set to English temporarily. Then return to the
DISPLAY SETUP screen and set the correct language.
5.2.3.1.1.2 DECIMAL
The DECIMAL parameter is used to determine the decimal separator, a comma or a
period. Select the desired decimal separator using the right or left arrow key and press
“ENTER” to accept the selection.
5.2.3.1.1.3 KEY AUDIO
The KEY AUDIO parameter (F1 and F3 Keys pressed simultaneously) enables or
disables the key press beep.
5.2.3.1.2 COMM SETUP
The COMM SETUP (COMMUNICATIONS SETUP) menu contains the serial inter-
face parameters. The parameters in the menu are—BAUD RATE and LINEFEED.
5.2.3.1.2.1 BAUD RATE
The BAUD RATE parameter determines the serial communication transmission rate or
baud rate.
BAUD may be programmed to 1200, 2400, 4800, 9600, 19200, or 38400 baud.
5.2.3.1.2.2 LINEFEED
The LINEFEED enables (On) or disables (Off) transmission of a line feed character
(LF, ASCII 10) after transmission of any carriage-return. The LINEFEED default set-
ting is on. The line feed parameter can be turned on or off as needed by the user.
