Chapter: Mechanical Drawings PCB: Mounting Holes
page 112 Beckhoff New Automation Technology CB3064-xxxx
7 Mechanical Drawings
Notice
All dimensions are in mil (1 mil = 0,0254 mm).
7.1 PCB: Mounting Holes
3858
157
1102
984
H4
H1
3865
5630
Mounting Holes H1 - H5: Inner diameter 126, Outer diameter 252
H2
dimension = mil
H5
H3
