Beckhoff CB3064 Series User Manual

Memory Chapter: Connectors
Beckhoff New Automation Technology CB3064-xxxx page 19
4.3 Memory
The CB3064 is equipped with two SO-DIMM260 sockets for DDR4-2133-RAM. For technical and
mechanical reasons it is possible that particular memory modules cannot be employed. Please ask your
distributor for recommended memory modules
With currently available memory modules a memory extension up to 32 GByte is possible.
All timing parameters for different memory modules are automatically set by BIOS.
Description
Name
Pin
Name
Description
Ground
GND
1
2
GND
Ground
Data lane 5
DQ5
3
4
DQ4
Data lane 4
Ground
GND
5
6
GND
Ground
Data lane 1
DQ1
7
8
DQ0
Data lane 0
Ground
GND
9
10
GND
Ground
Data Strobe 0 -
DQS0_c
11
12
NC
Reserved
Data Strobe 0 +
DQS0_t
13
14
GND
Ground
Ground
GND
15
16
DQ6
Data lane 6
Data lane 7
DQ7
17
18
GND
Ground
Ground
GND
19
20
DQ2
Data lane 2
Data lane 3
DQ3
21
22
GND
Ground
Ground
GND
23
24
DQ12
Data lane 12
Data lane 13
DQ13
25
26
GND
Ground
Ground
GND
27
28
DQ8
Data lane 8
Data lane 9
DQ9
29
30
GND
Ground
Ground
GND
31
32
DQS1_c
Data Strobe 1 -
Reserved
NC
33
34
DQS1_t
Data Strobe 1 +
Ground
GND
35
36
GND
Ground
Data lane 15
DQ15
37
38
DQ14
Data lane 14
Ground
GND
39
40
GND
Ground
Data lane 10
DQ10
41
42
DQ11
Data lane 11
Ground
GND
43
44
GND
Ground
Data lane 21
DQ21
45
46
DQ20
Data lane 20
Ground
GND
47
48
GND
Ground
Data lane 17
DQ17
49
50
DQ16
Data lane 16
Ground
GND
51
52
GND
Ground
