Power Input Chapter: Detailed Description
Beckhoff New Automation Technology CB3064-xxxx page 15
3 Detailed Description
3.1 Power Input
The connector for power supply is a 2x10-pin connector.
The 12V voltage supply is needed for employment of PCI-Express cards and FAN connectors. COM RXD
and TXD also can be used for PSU, e.g. the UPS functionality.
Communication is carried out via SMBus signaling (SMB_CLK/SMB_DAT).
Only for use with Beckhoff-certified PSU!
The CB3064 is designated for use with the Beckhoff PSU CA2000-0021 only.
3.2 SUPS
Optionally the CB3064 can be equipped with a plug-in SUPS, which can keep the board alive over a short
period of time in case of power failure or voltage fluctuation. The exact amount of time is hard to predict
as it also depends on factors such as the SUPS' capacitors and the boards' power consumption etc. The
capacitors size is only limited by the required space.
Do not use accumulator and S-UPS simultaneously!
The CB3064 can be used either with an accumulator or with an S-UPS module.
To avoid loss of data in case of a power fail, both components may not be used
simultaneously!
3.3 CPU
The motherboard is based on Intel®'s Q170 chipset and employs an Intel® Core™, Pentium™ or
Celeron™ processor of the Skylake-S family.
Such processors are optimized for real-time systems with a low power consumption, while at the same
time providing state-of-the-art computing performance and a huge I/O flexibilty. The CPUs feature a very
low power consumption and, depending on the variant, up to 2.7GHz processor base frequency. They
also offer many features known from the desktop range such as SSE4.1/4.2, loadable microcode etc.
The employed Intel®-CPUs operate in an extended range of thermal conditions and therefore are capable
for use in industrial systems.
3.4 Memory
Conventional SO-DIMM260 memory modules, as familiar from notebook computers, are used to equip
the board with memory. For technical and mechanical reasons it is possible that particular memory
modules cannot be employed. Please ask your distributor for recommended memory modules.
With currently available SO-DIMM260 modules a memory extension up to 32 GByte is possible
(DDR4-2133).
If both memory sockets are in use, notice that you must use identical memory modules.
All timing parameters for different memory modules are automatically set by BIOS.
Driver Compatibility
For optimal driver compatibility we recommend the use of a Microsoft®
Windows® 8 operating system.
