Page #24 background image
Chapter: Connectors DVI/HDMI/DisplayPort and USB3.0
page 24 Beckhoff New Automation Technology CB3064-xxxx
Pin
Name
Description
18
N/C
reserved
19
N/C
reserved
20
SSRX#
Super Speed receiver -
21
SSRX
Super Speed receiver +
22
USB#
USB -
23
USB
USB +
24
SSTX#
Super Speed transmitter -
25
SSTX
Super Speed transmitter
26
3.3V
3.3V supply
27
3.3V
3.3V supply
28
VCC
5V supply
29
VCC
5V supply
30
VCC
5V supply
