Beckhoff CP2712 - Fig. 18 Cp27 Xx_Wiring Diagram C9900-U332

Commissioning
CP27xx30 Version: 2.0
1 2 3
4
5
6
7
8
Battery
24 V
Power
24 V DC
+UPS
+ +
PC_ON
Power status
- -
GND
+24 V
PTC
24 V/3,4 Ah
30 V/9 A
C9900-U332 battery pack
1
2
3
4
5
6 7 8
L max = 10 m
1,5 mm / AWG14
2
X1 X2
ext. switch
N0 N0
X1
X2
Power status
-
+
UPS Output
0 V24 V DC
Industrial PC power connector
Fig.18: CP27xx_wiring diagram C9900-U332
