Commissioning
Fig.119: Selecting the correct motor XML file
• All required parameters are then set, and the motor can be put into operation (see Fig. CoE
parameters of the motor XML file).
Fig.120: CoE parameters of the motor XML file
Note
Startup list
Any further application-specific settings should also be implemented in the Startup list. Oth-
erwise the modified settings will be overwritten next time the terminal starts up.
EL72x1-0010 95Version: 2.0
