115 DeepMind 12 User Manual
Chorus-D (DIMENSIONAL CHORUS)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1 ON On — OFF ON Allows the eect to be turned On or O.
2 MOD Mode — M ST Switches the operation between Mono and Stereo modes.
3* MIX Mix % 0.0% 100% Controls the mix (or ratio) of wet (processed) and dry (unprocessed) signals.
4 SW1 Sw1 — OFF ON Engages level one intensity (minimum).
5 SW2 Sw2 — OFF ON Engages level two intensity.
6 SW3 Sw3 — OFF ON Engages level three intensity.
7 SW4 Sw4 — OFF ON Engages level four intensity (maximum).
* These parameters are available as modulation destinations in the Modulation Matrix
Flanger (STEREO FLANGER)
No DM12 REF PARAMETER UNITS MIN MAX DESCRIPTION
1* SPD Speed Hz
0.0 Hz
5 Hz Sets the modulation speed. Time synchronised options from 4 to 1/64 bars.
2* WDL WidthL %
0.0% 100%
Determines the amount of modulated delay in the left channel.
3* WDR WidthR % 0.0% 100% Determines the amount of modulated delay in the right channel.
4 DLL DelayL ms 0.5 ms 20.0 ms Sets the total amount of delay for the left channel.
5 DLR DelayR ms
0.5 ms 20.0 ms
Sets the total amount of delay for the right channel.
6* MIX Mix % 0.0% 100% Controls the mix (or ratio) of wet (processed) and dry (unprocessed) signals.
7* LC LoCut Hz 10.0 Hz 500.0 Hz Allows the low frequencies in the signal to be reduced.
8* HC Hi Cut Hz
200.0 Hz 20000.0 Hz
Allows the high frequencies in the signal to be reduced.
9 PHS Phase — 0.0 180.0 Adjusts the phase oset of the LFO between left and right channel.
10* FLC FeedLC Hz 10.0 Hz 500.0 Hz Adjusts the low cut lter frequency in the feedback path.
11* FHC FeedHC Hz
200.0 Hz 20000.0 Hz
Adjusts the high cut lter frequency in the feedback path.
12* FD Feed % -90.0% 90.0% Controls the percentage of positive or negative feedback.
* These parameters are available as modulation destinations in the Modulation Matrix
