Configuration – Speed Controller – Motor M1 + M2
Dual mixer
If no mixer function is used, both motors M1 and M2 can be used completely
separate. Prop #1 (X2/1) controls motor M1 and prop #2 (X2/2) motor M2, just like
two separate speed controller.
For tracked vehicles and ships with two drive motors different dual mixer are
available. Dual mixer combine the information of throttle channel #1 and steering
channel #2 and control both motors consequently.
Dual mixer #1:
Standard dual mixer (mixing ratio 1:1)
Dual mixer #2:
Less steering than with dual mixer #1
(mixing ratio 1:0,75)
Dual mixer #3:
Less steering than with dual mixer #2
(mixing ratio 1:0,5)
Dual mixer #4:
Like dual mixer # 1, however, only 1 chain is activated at table
turning
