GB Sound speed controller SFR-1
06.02.2019 BEIER-Electronic 47
Kraftwerk EasyBus lighting boards
The SFR-1 can also directly control the EasyBus lighting boards from Kraftwerk. This
considerably simplifies the connection of the lighting. The signal for the EasyBus
lighting boards is available at slot X5/1 of the SFR-1. Attention: Here an EasyBus
adapter with matching connector (servo plug) is needed!
Please note:
The EasyBus lighting boards or the EasyBus adapter have to be connected at X5/1
(Servo 1) of the SFR-1. Therefore, the servo output X5/1 can not be used to connect
a servo anymore!
The 16 switching outputs of the SFR-1 can nevertheless be used for further lighting.
The EasyBus lighting boards require at least the software version V4.08 to work with
the SFR-1. If the lighting boards have an older software version, they can be updated
via the Kraftwerk software "ControlPanel" and a KLM. Alternatively, the lighting
boards can also be sent to Kraftwerk for an update.
If Kraftwerk EasyBus lighting boards are to be connected to the SFR-1, this must be
activated in the Sound-Teacher (see page 52). Further settings are not absolutely
necessary for the lighting boards. Of course, the behavior of the lighting can still be
set under „Configuration“ „Outputs“ „Output options“.
With the Kraftwerk EasyBus lighting boards, there are, however, a few slight
restrictions that should be noted:
• The lighting boards can not be controlled via output sequences
• The flickering of the lights during starting can not be set by the Sound-Teacher
(only via the Kraftwerk ControlPanel)
• The light bulb effect can not be set by the Sound-Teacher (only via the
Kraftwerk ControlPanel)
• The xenon effect can not be set by the Sound-Teacher (only via the Kraftwerk
ControlPanel)
