GB Sound speed controller SFR-1
6 BEIER-Electronic 06.02.2019
Technische Daten
Supply Voltage (U
b
):
6 – 18 V DC
Power consumption:
Bias current: approx. 1 mA
Standby current (sound, motor and outputs off):
approx. 80 mA
Motor current:
Max. 30 A continuous current,
60 A short-term current (1 minute)
BEC voltage:
approx. 5,6 V
BEC current:
max. 3 A continuous current, 5 A short term (10
seconds)
Proportional inputs:
6 inputs
Supported protocols:
• PPM / PCM (1,000 - 2,000 ms)
• Sum signal S-Bus (max. 16 channels)
• Sum signal SUMD/SUMD3 (max. 16
channels)
• Nautic / Multiswitch / Multikanal / EMS
Servo outputs:
3 outputs (1,000 - 2,000 ms)
Switching outputs:
16 outputs (npn – open collector),
max. 1,5 A each output, the total current of all
outputs is not allowed to exceed 3,0A
Audio amplifier:
20 W (mono)
Recommended loudspeaker:
4 – 8 Ω
Volume setting:
With extra poti (100 kΩ) and/or by the radio
Memory for sound files:
Micro SD card (1 to 32 GB)
May. length of sound:
approx. 180 minutes per 1 GB
Supported file format:
WAV-Format, 8/16 Bit, Mono/Stereo, 22/44 kHz
Sound output:
16 Bit, Mono, 44 kHz
Number of possible sounds:
• 5 running steps/gears (internally in up to 255
steps accelerated)
• 8 change sounds between the running
steps/gears
• Turn on noise, turn off noise, starting noise,
stopping noise, idling noise, brake noise,
reverse engine noise, curve squeal, flashing
lights sound
• 30 additional sounds (for example via prop.-
channels)
• 8 random sounds (random generator)
• 30 tracks for WAV-Player
Random sound generator:
Times between 1 to 999s adjustable
Additional ports:
• Programming interface for data cable
• Port for infrared diode of light module
SM-IR-16-2
