GB Sound speed controller SFR-1
06.02.2019 BEIER-Electronic 91
Nautic mode
If the nautic mode is active, you can see the received nautic signals here by pressing
on „read“. This is only necessary in a few cases, e.g. if you want to analyze a new
switching module, or if errors occur at the transmitter side in nautic mode.
Outputs
If one of the 16 outputs are switched on, it will be indicated with a green circle.
To check all 16 outputs one by one you can activate the box „Test“. This is helpful to
control your wiring without using the transmitter. This diagnosis function works only
with live diagnosis and a data cable.
Miscellaneous
The values shown here are intended primarily for internal audit purposes.
Live-diagnosis with datacable
The additional datacable K-USB-2 is needed for live-diagnosis. It is connected to
X11. The brown cable points to the SD-card.
A live-diagnosis using the data cable is generally only useful when the SFR-1 in the
model is completely installed; wired and all necessary equipment is switched on (e.g.
transmitter and receiver).
Approach for diagnosis using the datacable:
1. Switch on transmitter and receiver.
2. Connect SFR-1 to supply voltage.
3. Connect datacable to X11 and to your computer.
4. Start SFR-1 Sound-Teacher.
5. Go to "Data cable" and click on "Diagnosis via datacable".
6. The diagnosis window opens.
Optionally, the live diagnosis can also be recorded on the hard disk of the PC and
played back later.
