2-3
2 Installation
Attention
Installation and putting into operation may only be carried out by mechanically
and electrically qualified staff. These people must read and understand the
complete operating manual before starting.
2.1 Technical data
Dimensions 1.600 x 750 x 1.300mm (LxWxH)
Table height 830 mm
Weight 220 kg
Mains power 220 V AC
Power consumption 0,7 kW
Fuse 10 A
Req. air pressure 6 bar
Req. air quality oil-free
Air consumption 5 NL/WD
2.2 Mechanical installation
Attention
Check before starting the installation, whether the desired location meets the
requirements (see chapter 2.1, technical data). This is very important
regarding the stability of the ground.
2.2.1 Unpack and put up
1. Remove the packing material and possible transportation protections.
2. Position the machine on a solid and horizontal ground.
3. Level the machine to a horizontal stand using the adjustable frame feet.
