2-26
02 Main clamp laterally Y02 2 X35 pin 14
56 Pocket welt turner device bed slide Y56 56 X26 Pin 22
57 Pocket welt t. device outside seam st. Y57 57 X25 Pin 12
58 Pocket welt t. device outside seam e. Y58 58 X25 Pin 11
59 Pocket welt turner device up Y59 59 X26 Pin 21
31 Zipperfinger move Y60 60 X26 Pin 23
32 Ziipperfinger up/down Y61 X26 Pin 24
20 Needle strip big Y08 08/08.1 X26 Pin 25
5.5.2 Diagnostics
1. Press the P-key.
2. Press the F6-key.
3. Press the F3-key.
Here you can choose from six different sub-menus, with which you are able
to check system components individually.
5.5.2.1 Service Test
ATTENTION
These tests may only be executed by service technicians of the company
Beisler. The complete loss of all data can easily occur due to false
operations.
5.5.2.2 Sewing motor
1. Press the P-key.
2. Press the F6-key.
3. Press the F3-key.
4. Press the F2-key.
Here, four tests for the sewing motor are contained. Select the desired test
by pressing the corresponding F-key:
F1 Select sewing motor
Here the actual value is compared with the must value of revs of the sewing
motor. After opening the test, you can enter the desired revs using the
number keys.
ATTENTION
The insertion station must be swung out and all threats and bobbins must be
removed from the sewing head before the test can be executed. Beisler
sewing heads may only be run with revs up to 2500 Rpm.
Enter the desired revs of the motor and press the ENT-key. The sewing head
starts and the measured actual value is displayed.
Press the P-key to terminate the test.
