2-21
5 Maintenance of the machine
This machine works nearly free of maintenance. To achieve the maximum
ability of the machine for a long term, some regular maintenance duties are
required.
Danger
Before starting maintenance and repair duties, the following power down
procedures are to be executed. Otherwise there could be danger to life!
Cut off mains power
• switch the mains / emergency stop switch to '0' and assure that it can't be
switched on
• check whether the machine is without current and that there is no statical
loading
Switch off pneumatic system
• close the main gauge
• ventilate all pipes and gauges
5.1 Water separator at air connector
The air connector is equipped with an automatic water separator. If the air
supply looses pressure, the contained water will be let out automatically.
5.2 Grease linear guiding
At least once a year, the linear guiding must be greased with normal ball-
bearing grease:
