Beisler 100 - Page 45

2-25
5.5.1.2 Available outputs
Standard equipment
No. Description Valve No. Cylinder Occupation
No. State
01 Bobbin threat cutter Y01 01 X25 Pin 01
03 Center knife motion Y03 03 X26 Pin 26
04 Mitre knife up Y04 04/04.1 X25 Pin 16
11 Tension release Y11 11 X25 Pin 02
24 Folder upwards Y24 24 no airpressure X25 Pin 07
25 Folder downwards Y25 25 no air pressure X25 Pin 08
Clamp quick adjustment Y32 32
33 Pocket pouch clamp right Y33 33 X26 Pin 20
34 Folding slide left Y34 34 X25 Pin 13
35 Folding slide right Y35 35 X25 Pin 14
36 Pocket pouch clamp left Y36 36 X26 Pin 19
38 Both main clamps open Y38 39/40 no air pressure X25 Pin 04
39 Main clamp left Y39 39 no air pressure X25 Pin 05
40 Main clamp right Y40 40 no air pressure X25 Pin 06
41 Top threat catcher Y41 41 X25 Pin 03
48 Center knife actuator Y48 48 X25 Pin 15
Options
12 Mitre knife middle stop Y12 X26 Pin 21
05 Mitre knife left seam end Y05 05.1 X25 Pin 11
06 Mitre knife left seam start Y06 06 X25 Pin 12
53 Needle switch off right Y53 53 no air pressure X26 Pin 22
54 Needle switch off left Y54 54 no air pressure X26 Pin 23
09 Vylene cutting Y09 9 X26 Pin 31
51 Vylene release Y51 51 X26 Pin 30
60 Vylene feed motion Y62 60 X26 Pin 29
13 Stacker Y13 X26 Pin 18
23 Take off roller Y23 23 X26 Pin 17
20 Dart stretcher Y20 20 X26 Pin 25
21 Scissor swing in Y21 21 X26 Pin 28
22 Scissor cut Y22 22 X26 Pin 27
10 Vacuum Y10 10 X25 Pin 10
42 Piping blowing system Y42 X25 Pin 09
Clamp quick adj. trouser/jacket Y50 50
01 Blowing bobbin detector Y55 56 X25 Pin 01
