Installation and connection
18
RCMB300-series_D00372_01_M_XXEN/06.2019
4.2 Installing the device
4.2.1 Dimension diagrams
Fig. 4.1: Dimension diagrams CTBC… and RCMB30…
all dimensions in mm, tolerance ±0.5 mm
CTBC20(P)/CTBC35(P) CTBC60(P)
CTBC120(P)/CTBC210(P) RCMB30…
Type a b c d e f g
RCMB30…-CTBC20(P)
81 112 37 ø 20 46 60
RCMB30…-CTBC35(P)
97 130 47 ø 35 46 61
RCMB30…-CTBC60(P)
126 158 57 ø 60 56 78
RCMB30…-CTBC120(P)
188 232 96 ø 120 65 96 139
RCMB30…-CTBC210(P)
302 346 153 ø 210 67 113 277
RCMB30…
74 37 44 2 4.6
d
b
f
c
ae
d
e
f
c
b
a
g
a
d
e
c
f
b
c
b
d
a
