7.7 Control commands
Register Property Format Description
Comment
Unit
Value
Factory
setting
20000 RW UINT16 Device test
Manual device tripping test.
Same behaviour as test button.
Read
1 = test inactive/completed
2 = test running
Write
2 = start test
1
20001 WO UINT16 Device reset
Deleting fault and alarm messages. Same behav-
iour as reset button.
1 = perform reset
20002 RW UINT16 Relay 1 test
1 = test inactive (normal function)
2 = relay energised
3 = relay de-energised
Switches automatically back to 1 = test inactive
after one minute at the latest.
1
20003 RW UINT16 Relay 2 test 1
20004 WO UINT16 Clear history memory
1 = perform deletion
(secured via reg. 12005)
20005 RW UINT16
Allow register write
access
Flag to allow changing important registers. Is
automatically deactivated after five seconds.
1 = deny
2 = allow
1
20006 RW UINT16 Activate device signalling
Makes the LED flash quickly red and green in
alternation to detect the device in its environ-
ment faster. Is automatically deactivated after
one minute.
1 = inactive; 2 = active
1
20007 WO UINT16
Load factory settings
(without interface)
Loads all factory settings except the interface
parameters.
Secured via register 20005.
1 = restore factory settings
20008 WO UINT16
Load factory settings
(all parameters)
Loads all factory settings including the interface
parameters.
Secured via register 20005.
1 = restore factory settings
