Modbus register
35
RCMB300-series_D00372_01_M_XXEN/06.2019
7.3 Detailed measured values
Tab. 7.2: Detailed measured values
Notes
1)
HiByte: Test status
LoByte: Alarm status
2)
HiByte: Range
LoByte: Unit
3)
see Table 7.4
Register Property Format Description Value/unit
4000 RO UINT16
AC
Measuring channel number (1)
4001 RO Float32 Residual current measured value (AC) A
4003 RO UINT16
Test and alarm status
1)
4004 RO UINT16
Range and unit
2)
4005 RO UINT16 Description
4006…4015 Reserved
4016 RO UINT16
DC
Measuring channel number (2)
4017 RO Float32 Residual current measured value (DC) A
4019 RO UINT16
Test and alarm status
1)
4020 RO UINT16
Range and unit
2)
4021 RO UINT16 Description
4022…4031 Reserved
4032 RO UINT16
RMS
Measuring channel number (3)
4033 RO Float32 Residual current measured value (RMS) A
4035 RO UINT16
Test and alarm status
1)
4036 RO UINT16
Range and unit
2)
4037 RO UINT16 Description
4038…4047 Reserved
4048 RO UINT16
Device
error/sta-
tus infor-
mation
Measuring channel number (4)
4049 RO FLOAT32
Device error and status information
3)
Device/info code
4051 RO UINT16
Test and alarm status
1)
4052 RO UINT16
Range and unit
2)
4053 RO UINT16 Description
4054…7999 Reserved
