33
RCMB300-series_D00372_01_M_XXEN/06.2019
7.1.5 Alarm assignments
7.1.6 Descriptions
7.2 Device information
Bit number Description Bit number Description
0 Start alarm (relay 1) 16 Start alarm (relay 2)
1 Device error (relay 1) 17 Device error (relay 2)
2 Manual self test (relay 1) 18 Manual self test (relay 2)
3 AC residual current (relay 1) 19 AC residual current (relay 2)
4 DC residual current (relay 1) 20 DC residual current (relay 2)
5 RMS residual current (relay 1) 21 RMS residual current (relay 2)
6…15 Reserved 22…31 Reserved
Description Value
Device error 115
DC fault current 155
AC fault current 156
RMS fault current 420
"inactive" 1021
"none" 1022
"invalid" 1023
Register
Property
Format Description Value/unit/comment Factory settings
0…999 Reserved
1000 RO UINT32
Modbus
test register
Is used to configure the interface (endianess, byte
order, etc.)
0x12345678
1002 RO
String UTF-
8
Device name
Maximum 32 characters
(\0 = end character)
Character is in the LoByte
Example:
RCMB301\0
1034 RO
String UTF-
8
Article number
Example:
B74043122\0
1066 RO
String UTF-
8
Serial number
1098 RO
String UTF-
8
Manufacturer name
Maximum 96 characters
(\0 = end character)
Character is in the LoByte
Bender GmbH &
Co. KG\0
1194 RO UINT16
Application
D number
579
(MRCDB3…)
610(RCMB3…)
