7.4 General measured values
Tab. 7.3: Simple measured values
Notes
1)
see Table 7.4
2
) Same data as register 8000-8014, but the maximum values or cumulative values are output
since the last readout.
In the case of the DC measured value, the highest value is stored.
Register Property Format Description
Unit
Value
Comment
8000 RO Float32
Measured value I
Δn
(AC)
A
8002 RO Float32
Measured value I
Δn
(DC)
A
8004 RO Float32
Measured value I
Δn
(RMS)
A
8006 RO Float32
Device error and status information
1)
Device/info code
8008 RO UINT32 Number of alarms
8010 RO Float32
Measured value I
Δn
(AC unfiltered)
A
8012 RO Float32
Measured value I
Δn
(RMS unfiltered)
A
8014 RO UINT32 Tripping status (alarm assignment that led to tripping)
Bit, binary coded
HiWord: Relay 2
LoWord: Relay 1
8016 RO Float32
Measured value I
Δn max.
(AC)
2)
A
8018 RO Float32
Measured value I
Δn max.
(DC)
2)
A
8020 RO Float32
Measured value I
Δn max.
(RMS)
2)
A
8022 RO Float32
Device error and status information
1)2)
Device/info code
8024 RO UINT32
Number of alarms
2)
-
8026 RO Float32
Measured value I
Δn max.
(AC unfiltered)
2)
A
8028 RO Float32
Measured value I
Δn max.
(RMS unfiltered)
2)
A
8030 RO UINT32
Trigger status
2)
Bit, binary coded
HiWord: Relay 2
LoWord: Relay 1
8032… 1200 Reserved
