Installation and connection

RCMB300-series_D00372_01_M_XXEN/06.2019

4.6 Connection RS-485 interface (Modbus RTU)

Fig. 4.4: Connection RS-485 interface

The internal 120 Ω terminating resistor can be connected by using the wire jumper.

The internal 120 Ω terminating resistor can be connected by means of the DIP switch .

X1 X2

120 Ω

MRCDB30…

first device

wire jumper

COM465IP

last device

DIP switch
