HD-973P Series Multi-Level Parking Lift 11 P/N 5900076 — Rev. B3 — January 2024
HD-973P
Upper Platform Lower Platform
Lifting capacity 7,000 lbs. (3,175 kg) 9,000 lbs. (4,082 kg)
a – Total Length (Platforms Lowered)
241.75 in (6,137 mm)
b – Total Width - Base Plates (outside to
outside)
110.47 ±.125 in. (2,806 mm ±3mm)
c – Post Height
(3.25 in. max. for safety ladder adj.)
161 in. (4,093 mm)
d – Outside Posts Length - Base
Plates (outside to outside)
197.75 in. (5,024 mm)
e – Posts (inside to inside)
100 in. (2,541 mm)
f – Maximum rise (upper)
139.5 in. (3,544 mm)
g –Maximum rise (lower)
70 in. (1,777 mm)
h – Runway Height – Down Position
10.75 in. (270 mm) N/A
i – Runway Height – Down Position
N/A 5 in. (128 mm)
j – Runway Width
19 in. (482 mm)
k – Distance between Runways
35 in. – 41 in. (887 mm –1,045 mm) Max.
l – Runway thickness (upper platform)
5.5 in. (137 mm) N/A
m – Runway thickness (lower platform)
N/A 4.75 in. (123 mm)
n – Drive through height (Top Lock)
2
67.25 in. (1,711 mm)
o – Drive through width (both platforms)
86.5 in. (2,201 mm)
p – Distance to Ramp (upper)
109.75 in. (2,790 mm)
q – Distance to Ramp (lower)
51 in. (1,300 mm)
r – Runway Length
180.25 in. (4,581 mm) 165.5 in. (4,203 mm)
Min. wheelbase @ rated capacity
1
130 in. (3,302 mm) 120 in. (3,175 mm)
Min. wheelbase @ 75% capacity
1
110 in. (2,794 mm) 100 in. (2,667 mm)
Min. wheelbase @ 50% capacity
1
95 in. (2,413 mm) 85 in. (2,159 mm)
Min. wheelbase @ 25% capacity
1
75 in. (1,905 mm) 70 in. (1,778 mm)
Top Safety Lock (top of Platform) 144 in. (3,654 mm) 72.25 in. (1,837 mm)
Safety Lock Positions 31 every 4 in. (102 mm) 13 every 4 in. (102 mm)
Lifting time 90 seconds 50 seconds
Motor 110 or 220 VAC, 60 Hz, 1 Ph (special voltages available)
1
The Runways support less weight than their rated capacity as the Vehicle wheelbase reduces. Vehicles with a short
wheelbase have wheels closer to the middle of the Runway, where there is less strength. For example, the maximum
weight permitted on the Top Platform for a Vehicle with a wheelbase of 95 in. is 50 percent of the full rated capacity or
3,500 lbs.
2
All measurements are taken with the Safety Ladders adjusted to their upper maximum.
Important: All posts include fasteners extending horizontally ≈.65 in. (16.5 mm) on all four posts. This larger
dimension should not be used to create the chalk lines for Lift installation, but the additional clearance
around the Posts is required.
Specifications subject to change without notice.
