HD-973P Series Multi-Level Parking Lift 17 P/N 5900076 — Rev. B3 — January 2024
• Side Clearances. You must leave room around the Lift. Leave at least three feet (36 inches)
clear on the sides of the Lift.
• Front and Rear clearances. You must leave room around the Lift. Leave at least two feet (24
inches) clear on the Front of the Lift, and no obstructions at all at the Rear of the Lift so you can
safely drive Vehicles on and off the Runways.
• Power. You need a power source for the Power Unit.
• Outdoor installations. Your Lift is approved for indoor installation and use only. Outdoor
installation is prohibited. For Outdoor installations see Models HD-973PG / PXG.
• Floor. Only install the Lift on a flat, concrete floor; do not install on asphalt or any other surface.
The surface must be level; do not install if the surface has more than three degrees of slope.
⚠ WARNING Installing your Lift on a surface with more than three degrees of slope could lead to
injury or even death; only install the Lift on a level floor. If your floor is not level,
consider making the floor level or using a different location.
• Shimming. If your concrete floor is not completely level, you can use Shims under the Base
plates, as needed, to level the Lift.
To estimate your Shim requirements, use a transit level and targets to check for flatness. Use the
provided Shims, as necessary.
NOTICE Do not shim a Post more than half an inch using the provided Shims and Anchor
Bolts. A maximum shim of 2 inches is possible by ordering optional Shim Plates.
Contact BendPak at (800) 253-2363, select option 7 then 5 to order. Please
have the model and serial number of your Lift available.
• Concrete specifications. Do not install the Lift within 6 inches of cracked or defective
Concrete. Make sure the concrete is at least 6 inches thick, 3,000 PSI compressive strength, and
cured for a minimum of 28 days.
