HD-973P Series Multi-Level Parking Lift 59 P/N 5900076 — Rev. B3 — January 2024
Attach the JIC x NPT Nipple Fittings to each end of the Platform Selector Valve.
Gather the Hydraulic Hoses coming out from the Flex Tubes and bring them towards the Power
Unit.
Find the Hydraulic Hose for the Upper Platform and connect it to the Right side of the Valve.
Double check that you have the correct Hydraulic Hose.
Find the Hydraulic Hose for the Lower Platform and connect it to the Left side of the Valve.
5585173
5585312
