HD-973P Series Multi-Level Parking Lift 75 P/N 5900076 — Rev. B3 — January 2024
⚠ DANGER Pay careful attention when you are raising or lowering your Lift. If a person or pet is
trapped under the Lift, they could be injured or, in rare cases, killed.
• Platforms operate independently. Each Platform on the Lift operates independently; be sure
to double check that the handle on the Platform Selector Valve is turned in the direction of the
Platform you want to move.
• Get what you need out of the Vehicle before lifting it. It is frustrating to raise a Vehicle
and then realize you left something inside. Never raise your Lift with people in the
Vehicle.
• Make sure the Vehicle is balanced. If there is extra weight on one end or the other, remove
it or balance it before raising the Vehicle.
• Center the Vehicle’s wheels on the Runway. Centered wheels keep the Vehicle balanced.
Do not leave a Vehicle with its Tires on the Aluminum Decks that sit between the Runways.
To raise a Vehicle on the Upper Platform:
Double check that no one except the Lift operator is within 10 feet of the Lift.
Verify both Platforms are fully lowered. If not, move them down onto their Stop Blocks.
Drive a Vehicle onto the Runways.
Make sure all four wheels are completely on the Runways, as close to the center of the Runways
as possible.
⚠ CAUTION The Runways and Drive-up Ramps can be slippery when wet or icy; use care
driving your Vehicles onto the Runways.
Put the Vehicle into park and engage the parking brake. If your Vehicle has a manual transmission,
place the transmission in first gear.
Always chock the tires.
⚠ WARNING Chock Wheels to reduce the risk of property damage, personal injury, or loss of
life. NEVER park any vehicle on the Lift’s runways without placing two suitable
Wheel Chocks behind each rear tire so that the vehicle cannot roll backward
from Lift. Vehicles parked on Lift MUST also be placed in Park or First Gear
(Manual Transmission) with the Parking Brake fully applied.
Walk around the Lift to make sure no obstructions will interfere with the Vehicle being lifted.
Position yourself within reach of the Lift controls and clear of all moving parts and pinch points.
Verify the Platform Selector Valve handle is turned
straight up
for the Upper Platform.
Press the Up button on the Power Unit.
NOTICE As the Platform raises, you will hear the Safety Locks hitting the locking
position in the safety ladders and then passing them by; this is a normal occurrence.
When the Platform arrives at the desired height, move the platform Up a small amount more, then
release the Up button and press and hold the Lowering Handle. The Platform will lower onto the
most recently passed Safety Lock.
