PL-12000DP Series Parking Lift 4 P/N 5900285 — Rev. A1 — February 2023
Table of Contents
Introduction 4 Maintenance 67
Shipping Information 5 Troubleshooting 69
Safety Considerations 5 Wiring Diagrams 71
Components 8 Labels 72
Specifications 9 Parts Drawings 75
Installation Checklist 11 Maintenance Logs 93
Installation 12
Operation 65
Introduction
This Manual describes the PL-12000DP Series Parking Lifts.
PL-12000DP Double Wide Parking Lift
PL-12000DPS Double Wide Parking Lift –
Small footprint
Parking Lift, which allows double the number of Vehicles in the same parking area. Each individual
Platform supports up to 6,000 lbs. (2,722 kg).
The PL-12000DP uses
two
hydraulic Power Units; each Platform uses a separate Power Unit and
Lifting Cables, Hydraulic Hose, Return Line, Air Line, and includes one pair of Aluminum drive-up
ramps. Additional Aluminum drive-up ramp accessory kits are also available (5174705).
More information about the full line of BendPak products can be found at bendpak.com.
This Manual is mandatory reading for all users of PL-12000DP Series Parking Lifts,
including anyone who installs, uses, maintains, repairs, or wants to know more
about them.
⚠ DANGER Exercise caution when installing, operating, maintaining, or repairing this equipment;
failure to do so could result in property and product damage, injury, or loss of life.
Only authorized personnel are to operate this equipment. All repairs must be
performed by an authorized technician. Modifications to the Lift voids the warranty
and increases the chances of injury or property damage. Read and follow the
instructions on the labels on the unit.
Keep this Manual on or near the equipment so that anyone who uses or services it can read it.
If you are having issues, refer to the Troubleshooting section of this Manual for assistance.
Technical support and service is available from your dealer, on the Web at bendpak.com/support,
by email at support@bendpak.com, or by phone at (800) 253-2363, extension 196.
You may also contact BendPak for parts replacement information (please have the model and serial
number of your unit available) at (800) 253-2363, extension 191.
