1313
FLOOR PLAN
Model Configuration A Capacity
XPR-10A Narrow 3354 mm / 132” 10,000 LBS
XPR-10A Wide 3684 mm / 145” 10,000 LBS
Model Configuration A Capacity
XPR-10 Narrow 3353 mm / 132” 10,000 LBS
XPR-10 Wide 3683 mm / 145” 10,000 LBS
A
A
Approach
Approach

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BendPak XPR-10 and is the answer not in the manual?

BendPak XPR-10 Specifications

General IconGeneral
Capacity10, 000 lbs
Lift TypeTwo-Post Lift
Lifting Time45 seconds
Voltage220V
Minimum Height4.5 inches
Max Lift Height69 inches
Power Requirements220 VAC / 60 Hz / 1 Ph
Overall Height145" / 3683 mm
