1717
STEP 9
(Installing the Safeties and Safety Cable)
1. Install safety weldments on to each respective post.
(See Figs 9.1 - 9.2)
2. From the Off Side post insert the non-looped end of
the safety cable through the hole located to the right of the
Off Side safety weldment. (See Fig 9.3)
3. Route the cable under the sheave and route it towards
the Overhead Assembly. (See Fig 9.4)
4. Route the cable through the Overhead Assembly’s
safety sheave(s) and across the lift. (See Figs 9.5 - 9.6)
5. Route the cable the same way on the Power Side
going back down the post.
6. Route the cable over the top pin on the safety handle.
Insert the cable end through the hole on the threaded pin.
(See Fig 9.7)
7. Pull the slack out the safety cable and keep tension
on the cable as nuts are being tightened. Tighten jam
nuts on either side of the cable keeping the cable cen-
tered to the hole to secure it into place.
(See Fig 9.7)
WARNING!
DO NOT RUN POWER UNIT WITHOUT OIL. DAMAGE TO POWER UNIT PUMP CAN OCCUR.
THE POWER UNIT MUST BE KEPT DRY. DAMAGE TO POWER UNIT CAUSED BY WATER OR OTHER
LIQUIDS SUCH AS DETERGENTS, ACID ETC., IS NOT COVERED UNDER WARRANTY.
OPERATE LIFT ONLY BETWEEN TEMPERATURES OF 41 °- 104° F.
ANY IMPROPER ELECTRICAL INSTALLATION MAY DAMAGE POWER UNIT
MOTOR AND RESULTING DAMAGE WILL NOT BE COVERED UNDER WARRANTY.
MOTOR CAN NOT RUN ON 50HZ WITHOUT A PHYSICAL CHANGE IN MOTOR.
USE A SEPARATE CIRCUIT BREAKER FOR EACH POWER UNIT.
PROTECT EACH CIRCUIT WITH TIME DELAY FUSE OR CIRCUIT BREAKER.
FOR 208-230 VOLT, SINGLE PHASE, USE A 25 AMP FUSE.
FOR 208-230 VOLT, THREE PHASE, USE A 20 AMP FUSE.
FOR 380-440 VOLT, THREE PHASE, USE A 15 AMP FUSE.
Fig 9.1
Safety
Cable
Hairpin
Cotter
Power Side
Safety Weldment
Torsion
Spring
Safety
Clevis
Pin
Fig 9.2
Safety
Cable
Hairpin
Cotter
Off Side Safety
Weldment
Safety
Clevis
Pin
Torsion
Spring
To Next Page
