When removing the lift from shipping angles, pay close attention as the posts can slide and can cause injury. Prior
to removing the bolts make sure the posts are held securely by a fork lift or some other heavy lifting device.
PARTS INVENTORY
Be sure to take a complete inventory of parts prior to beginning installation.
Description Qty
Overhead Assembly 1
Front Lift Arm Assembly 2
Rear Lift Arm Assembly 2
Off Side Post with Carriage Assembly 1
Power Side Post with Carriage Assembly 1
Hydraulic Cylinder 2
Parts Box (Packing List Enclosed) 1
Parts Bag (Packaged in Part Box) 1
Hydraulic Power Unit 1

BendPak XPR-10 Specifications

General

Capacity	10, 000 lbs
Lift Type	Two-Post Lift
Lifting Time	45 seconds
Voltage	220V
Minimum Height	4.5 inches
Max Lift Height	69 inches
Power Requirements	220 VAC / 60 Hz / 1 Ph
Overall Height	145" / 3683 mm
