BendPak XPR-10 User Manual

2525
WARNING!
YOU MUST RE-INSTALL TOP CARRIAGE-STOP BOLT (SHOWN BELOW). TIGHTEN CARRIAGE-STOP BOLT
TO 2-3 FT.-LBS. OF TORQUE UPON FINAL INSTALLATION INSPECTION. THESE INSTRUCTIONS MUST BE
FOLLOWED TO ENSURE PROPER INSTALLATION AND OPERATION OF YOUR LIFT. FAILURE TO COMPLY WITH
THESE INSTRUCTIONS CAN RESULT IN SERIOUS BODILY INJURY AND/OR DEATH AND/OR VOID PRODUCT
WARRANTY. MANUFACTURER WILL ASSUME NO LIABILITY FOR LOSS OR DAMAGE OF ANY KIND, EXPRESSED
OR IMPLIED RESULTING FROM IMPROPER INSTALLATION OR USE OF THIS PRODUCT.

BendPak XPR-10 Specifications

General

Capacity	10, 000 lbs
Lift Type	Two-Post Lift
Lifting Time	45 seconds
Voltage	220V
Minimum Height	4.5 inches
Max Lift Height	69 inches
Power Requirements	220 VAC / 60 Hz / 1 Ph
Overall Height	145" / 3683 mm
