BendPak XPR-12CL User Manual

13
6. Route both Hoses in their respective Posts PRIOR to
standing up the Posts. When routing the Hydraulic Hose
through the Posts, make sure to route them through the
Retaining Clips welded inside each Post. Make sure
that the Hose is clear of any moving parts. It may be
necessary to tie the Hose clear of obstructions by using
nylon tie straps or wire. Refer to Step 10.
BE SURE TO ROUTE THE HYDRAULIC HOSES
THROUGH THE RETAINING CLIPS WELDED
INSIDE EACH POST.
Fig 3.7
EQUALIZER CABLE ROUTING
M10 Spring
Lock
Washer
Fig 3.6
M10 Hex
Head Bolt
M10 Flat
Washer
M10 Hex Nut
CABLE
THREADED
END
BUTTON
END
