STEP 5
(Installing The POWERSIDE Post)
1. BEFORE PROCEEDING, double the check measure-
ments and make certain that the bases of each Post are
aligned with the chalk line.
2. Using the Base Plate on the POWERSIDE Post as a
guide, drill each anchor hole in the concrete approximately
6” deep for 12K and 15K models and 8” for 18K models
using a rotary hammer drill and 3/4” concrete drill-bit. To
assure full holding power, do not ream the hole or allow the
drill to wobble. (See Fig. 5.1)
3. After drilling, remove dust thoroughly from each hole
making certain that the Post remains aligned with the chalk
line.
4. Assemble the Washers and Nuts on the Anchors then
tap into each hole with a hammer until the Washer rests
against the Base Plate. Be sure that if shimming is required
that enough threads are left exposed. (See Fig. 5.2)
5. Insert the shims as necessary under the Base Plate so
that when the Anchor Bolts are tightened, the Posts will be
plumb. (See Fig. 5.3)
6. With the shims and Anchor Bolts in place, tighten by
securing the Nut to the base then turning 3-5 full turns
clockwise. DO NOT use an impact wrench for this
procedure. (See Fig. 5.4)
STEP 6
(Mounting The OFFSIDE Post)
1. Position the OFFSIDE Post at the designated chalk
locations and secure to the oor following the same
procedures as outlined in STEP FIVE; Items 1-6.
Fig 5.1
Fig 5.3
NOTE:
BENDPAK LIFTS ARE SUPPLIED WITH INSTALLATION
INSTRUCTIONS AND CONCRETE FASTENERS
MEETING THE CRITERIA AS PRESCRIBED BY THE
AMERICAN NATIONAL STANDARD "AUTOMOTIVE
LIFTS - SAFETY REQUIREMENTS FOR
CONSTRUCTION, TESTING, AND VALIDATION"
ANSI/ALI ALCTV-2011. LIFT BUYERS
SHOULD CONTACT QUALIFIED PERSONS
REGARDING ANY SPECIAL REGIONAL,
STRUCTURAL AND/OR SEISMIC ANCHORING
REQUIREMENTS SPECIFIED BY ANY OTHER
AGENCIES AND/OR CODES SUCH AS THE UNIFORM
BUILDING CODE (UBC) AND/OR INTERNATIONAL
BUILDING CODE (IBC).
NOTE:
TO EASE INSTALLATION OF THE OVERHEAD
ASSEMBLY, IT HELPS TO KEEP THE ANCHOR
BOLTS LOOSE ON ONE OF THE POSTS UNTIL THE
OVERHEAD ASSEMBLY IS MOUNTED.
Fig 5.2
Tap Anchor Bolts into
each hole with a hammer
until the Washer rests against
the Base Plate.
Fig 5.4
Tighten Nut
3- Turns.
Do Not Use
Impact Wrench.
NOTE:
TO EASE THE INSTALLATION OF THE OVERHEAD
ASSEMBLY, IT HELPS TO KEEP THE ANCHOR BOLTS
LOOSE ON ONE OF THE POSTS UNTIL THE
OVERHEAD ASSEMBLY IS MOUNTED.
