45
OFF SIDE SAFETY
DETAIL C
SCALE 1 : 15
POWER SIDE SAFETY
DETAIL B
SCALE 1 : 15
1110mm
594-
1333mm
820-
B
2679
3353
3243
2367
DRIVE THRU
C
81-1960.6mm [3.2-77.2"]
70mm [2.75"] & 140mm [5.5"] ADAPTER
291-2170.6mm [11.5-85.5"] WITH
SHEET 3 OF 4
REV
DWG. NO.
A
SIZE
TITLE:
J
1645 LEMONWOOD DR. SANTA PAULA, CA 93060
XPR-9-F
XPR-9F LIFT ASSEMBLY
1:40
SCALE:
