46
DIMENSIONS ARE IN MM
☺
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
F
REPLACED PARTS:CABLE NUTS WITH 5535025,
WASHER Ø50x20x3mmW WITH 5545342,
POWER UNIT MOUNTING BOLTS WITH
5530010,SAFETY COVER BOLTS WITH 5530114,
CHANGED TEE FITTING DESCRIPTION
06/05/2008
TM
00180
G
CHANGED REV ON ITEM (800378
2.4mm x
7544LG. SAFTY CABLE)
07/23/2008
GJ
00226
H
UPDATED DRAWING, UPDATED BOM
REVISION, REPLACED 800375 WITH 5570108,
REPLACED OVAL SLEEVE WITH 5580210,
REPLACED WASHER WITH 5545347,
REPLACED 90-.25Long ElbowORing WITH
5550103, REPLACED 801105 WITH 5715003,
ADDED FOOT GUARDS FG-800420, 5730014,
5730015, ADDED HHB M10 x 1.5 x 10
09/29/2008
TM
00220
ITEM
NO.
PART NUMBER
DESCRIPTION
QTY
REV
1 800374
XP/XPR-9-FX GROUND PLATE
1
B
2 801073
XPR-9F/FX POWER SIDE POST ASSEMBLY
1
F
3 800295
XP/XPR-9F/FX OFF SIDE POST ASSEMBLY
1
C
4 800309
XP/XPR-9-F/FX CHAIN ROLLER ASSEMBLY
2
C
5 800868
XPR-9F/FX LIFT HEAD ASSEMBLY
2
D-003
6 800300
XP/XPR-9-F/FX TOP EQUALIZER PULLEY PLATE WELDMENT
2
B
7 700583
CYLINDER ASSEMBLY Ø 2.5 x 37
2
A
8 800124
XP/XPR-9/10 SHEAVE ASSEMBLY
6
B
9
AB-1551 POWER UNIT
POWER UNIT
1
--
10 800112
OFF SIDE COVER
2
A
11 800191
SAFETY CLEVIS PIN
2
C
12 800100
XP/XPR POWER SIDE SAFETY WELDMENT
1
B
13 800104
XP/XPR OFF SIDE SAFETY WELDMENT
1
B
14
MALE .25-.4375 TEE
MALE BULKHEAD TEE 1/4"NPT-7/16-20
1/4-18 NPT TO 37° FLARE
7/16-20 UNF 2B
1
--
15
90deg .25 NPT
FEMALE-.4375 MALE
90° ELBOW FEMALE 1/4-18 NPT TO 37° MALE FLARE 7/16-20 UNF 2B 1
3/8" LONG
1
--
16 5550103
FTG ELB -04 JIC -06 ORB
1
--
17
90deg.375NPT-.44
90° ELBOW 3/8-18 NPT TO 7/16-20 UNF MALE THREAD
2
--
18
90deg.375NPT
90° ELBOW 3/8-18 NPT TO 3/8-18 NPT MALE THREAD
2
--
19 800330
XP/XPR-9F/FX 3/8" NPT TUBE FITTING
2
--
20 5580210
Ø2.4mm OVAL CABLE CRIMP
1
A
21 5545347
WASHER, M12 FLAT WASHER
2
--
22
16 DIA. HAIRPIN
COTTER
Ø3.75 x 68mm
2
--
23 800200
2.5 WIRE DIA., Ø25.5x150 LG.
2
B
24
HN M12 X 1.75
HEX NUT
2
--
25 5535025
NUT M18 x 2.5 NL
2
--
26 5545342
WASHER M18 FLAT
2
-
27 5530010
HHB M8 x 1.25 x 25
4
--
28
8 x 15 x 2 LW
SPRING LOCK WASHER
4
--
29
HN M8 x 1.25
HEX NUT M8 x 1.25
4
--
30
HHB M10 x1.5 x 38 HEX HEAD BOLT M10 x 1.5 x 38
4
--
31 5530114
HHB M8 x 1.25 x 18
4
--
32
HN M10 X 1.5
HEX NUT
4
--
33
10 x 18 x 2.3 LW
SPRING LOCK WASHER
4
--
34
22 DIA. HAIRPIN
COTTER
Ø4.5 x 75mm
6
--
35
LP-800979
ALL XPR-9, XPR-10C/CX LOW PROFILE MEDIUM ARM ASSEMBLY
2
G
36
LP-800992
XPR-9FX/FDX/10ACX/10CX LOW PROFILE TRIPLE TELESCOPING ARM
2
G
37 800750
XPR-9/10 LIFT HEAD PIN WELDMENT
4
C
38 800106
SLIP ON LIFT PAD ASSEMBLY
4
PRE-005
39 800207
MX/XP/XPR/RJ SHORT LIFT PAD EXTENSION (113mm LG.)
4
D
40 800208
MX/XP/XPR LONG LIFT PAD EXTENSION (182mm LG.)
4
D
41
FG-801017
XPR-9F/FX/FD/FDX/10C/CX ARM FOOT GUARD (526mm)
2
E
42
FG-801018
XPR-9FX/FDX/10CX/ACX TRIPLE TELESCOPING ARM ASSEMBLY FOOT
GUARD (330mm)
2
D
43
HHB M10 x 1.5 x10
HEX HEAD BOLT
8
--
44 800392
Ø6.35 x 3150mm LG. POWER UNIT HYDRAULIC HOSE ASSEMBLY (124")
1
B
45 800378
XP/XPR-9-FX Ø2.4mm x 7544LG. SAFETY CABLE
1
B
46 5570108
XP/XPR-9FX HYDRAULIC HOSE ASSY Ø6.35 x 1524mm
2
A
47 800332
XP/XPR-9F/FX CYLINDER CHAIN
2
B
48 801076
CABLE ASSY Ø10mm x 9960
2
C
49 5715003
POWER UNIT VIBRATION DAMPENER
1
A
50 800316
XP/XPR-9F/FX, XP-12F CYLINDER LEVELING PLUG
2
C
51
P-543
XPR PLASTIC COVER BLOCK 105x80
2
A
52
FG-800420
XP/XPR-9F/9FX BOTTOM SHEAVE COVER
2
A
53 5730014
XP/XPR-9F/FD/FX/FDX POST ASSEMBLY LIFT HEAD FOOT GUARD R.H.
2
A
54 5730015
XP/XPR-9F/FD/FDX/FX POST ASSEMBLY LIFT HEAD FOOT GUARD L.H.
2
A
SHEET 1 OF 4
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
SIZE:
MATERIAL:
H
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
TM
XPR-9-FX
XPR-9FX LIFT ASSEMBLY
---
---
06/21/2007
DO NOT SCALE DRAWING
--
SCALE:
THIRD ANGLE PROJECTION
AC
01/10/2009
FG-800420,FG-801017,FG-801018,5730014,5730015 &
1.
HHB M10 x 1.5 x 10USED ONLY ON MODELS REQUIRING FOOT GUARDS
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
2.
