FRONT WHEEL AND BRAKE DISKS
CHAS
FRONT WHEEL DECOMPOSITION
4
4
Front Wheel Decomposition
Bearing
Inside Spacer
SQ.
SYMBOLS
INTERVENTION/DESCRIPTION
Q.TY
OBSERVATIONS
1
2
2
1
Decompose the pieces in the given order.
NOTE:
To install, invert the order of the removal
operations.
1
2
1
LS
LS
LS
