POWER SUPPLY
THROTTLED BODY REMOVAL
Throttled Body Removal
Screw
Throttled Body
O-Ring Gasket
5
154
SQ.
SYMBOLS
INTERVENTION/DESCRIPTION
Q.TY
OBSERVATIONS
1
2
3
6
1
3
Remove the pieces in the given order.
ENG
2
3
3
3
1
1
