3
42
C
P
COOLING LIQUID CONTROL
Park:
• the bike levelled.
2
1
N
•
NOTE:
• Place the bike on a suitable trestle.
• Ensure that the bike is in straight position.
ENGINE/COOLING LIQUID
CHK
ADJ
Check:
• the cooling liquid level
the cooling liquid level must be between the
maximum level reference (MAX) and that of the
minimum level (MIN) .
If below the minimum level notch top-up to the
correct level using recommended cooling liquid.
A
2
A
MIN
MAX
B
B
3
Remove:
• the right tank lid
See "FRAME 4.112" paragraph.
• the engine protection
See "FRAME 4.120" paragraph.
4
Remove:
• the radiator cap
WARNING
If the radiator is very hot, the liquid inside will be
pressurised. Do not remove the radiator cap with
the engine hot. Boiling hot liquid may leak, caus-
ing serious injuries. When the engine has cooled
down, open the radiator cap as follows:
Position a towel on the radiator cap and slowly
loosen the cap anti-clockwise to drain any residue
pressure.
When the usual hiss is no longer heard, press on
the radiator cap and loosen it anti-clockwise to
remove it.
C
4
C
