Benelli 2009 TREK1130 User Manual

HEAD DISTRIBUTION
ENG
DISTRIBUTION LID REMOVAL
5
1
14
1
2
3
4
5
6
10
11
7
8
9
12
15
16
14
14
13
Distribution Lid Removal
Nut
Bracket
Rubber Pad
Washer
Special Screw
Rubber Pad
Reel
Spark Plug
Rubber Pad
Special Screw
Rubber Pad
Distribution Lid
Lid Gasket
O-Ring Gasket
Quick Fitting
Seal Ring
SQ.
SYMBOLS
INTERVENTION/DESCRIPTION
Q.TY
OBSERVATIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
3
3
3
3
3
3
3
3
3
5
5
1
1
3
1
1
Remove the pieces in the given order.
Champion RG4HC - NGK CR9E
