CLUTCH
ENG
5
75
1
FRICTION DISKS CONTROL
The following procedure is applied to all friction disks.
Check:
• the friction disk
In the presence of damages/wear Replace all
friction disks.
Measure:
• the thickness of the friction disks
If out of specification Replace all friction disks.
2
N
M
NOTE:
Measure the friction disk in four points.
2
Friction disk thickness
<Limit> : 2.8 mm (0.110 in)
