4
61
Rear Brake Calliper Installation
Rear Brake Calliper
Screw
Rear Brake Tube
Washer
Special Screw
SQ.
SYMBOLS
INTERVENTION/DESCRIPTION
Q.TY
OBSERVATIONS
1
2
3
4
5
1
2
1
2
1
Install the pieces in the given order.
Restore the torque twice after having loosened.
NOTE:
Once operations have been completed, top-up
with brakes liquid.
FRONT AND REAR BRAKES
CHAS
REAR BRAKE CALLIPER INSTALLATION
LS
LS
NEW
NEW
T
.
R.
22 N m - 2.24 Kgf•m
T
.
R.
15 N m - 1.52 Kgf•m
2
2
1
5
4
4
3
