Benelli 2009 TREK1130 User Manual

FAIRING
CHAS
TANK INSTALLATION
4
119
Tank Installation
Petrol Tube Fitting
Tank Vent Tube
Petrol Pump Connector
Tank
Rubber Buffer
Bush
Special Screw
SQ.
SYMBOLS
INTERVENTION/DESCRIPTION
Q.TY
OBSERVATIONS
1
2
3
4
5
6
7
1
2
1
1
2
2
2
Install the pieces in the given order.
ATTENTION:
Remove special tool (B) using special tool (A)
rapidly connecting the petrol tube fitting.
LS
T
.
R.
12 N m - 1.22 Kgf•m
LS
T
.
R.
12 N m - 1.22 Kgf•m
LS
7
6
5
5
6
7
4
2
3
1
Special Tools: RAPID RELEASE KIT
Code: R180100143000
2
RAPID RELEASE KIT
A
B
