Programming chart
The programming chart on the previous two pages will help the installer
plan and carry out programming of the B-TEL99 dialler. The chart serves
as a programming guide, as it shows (for each parameter) the keys to
press (KEY column) the value to enter (DESCRIPTION column) and the
factory default (DEFAULT column).
It may be useful for the installer to make a copy of the chart for Installer re-
cords (useful when maintenance is required), and for future use as an in-
stallation plan for other systems. Blank spaces have been left at the top
and bottom of the chart for Installer details. The chart has been designed
to be kept inside a loose-leaf folder.
Following is a short description of the items shown in the programming
chart.
CUSTOMER (details) Specify the User name, address, telephone and other
details.
SYSTEM No. Specify the system number or code.
TESTED ON Specify the date of testing.
CHANNEL 1 (2) Specify the event (Fire/Burglary) which activates alarm channel
1 (2) of the B-TEL99 dialler.
CHANNEL 1 (2) TELEPHONE NUMBERS Specify the digits and pauses of the
telephone numbers assigned to channel 1 (2), and customer details.
INSTALLER PIN Specify the Installer PIN (if required).
MESSAGES Specify the contents of the alarm messages .
USER COMMAND PIN Specify the User Command PIN (if required).
+
For security reasons the Installer PIN should not be known to the User,
and vice versa.
OPTION 1) MESSAGE MANAGEMENT Specify and highlight (use a floures-
cent highlighter pen) the programmed message management.
OPTION 2) NUMBER OF CALL CYCLES Specify and highlight the pro-
grammed number of call cycles.
OPTION 3) MESSAGE PLAYBACK TIME Specify and highlight the pro-
grammed message playback time.
OPTION 4) DIALLING TYPE Specify and highlight the programmed dialling
type.
OPTION 5) DIAL-TONE CHECK Specify the programmed Dial-Tone check
status (Enabled/Disabled).
OPTION 6) VOICE ANSWER DETECTION Specify the programmed Voice An-
swer detection type.
OPTION 7) DIAL-TONE TYPE Specify the programmed dial-tone type.
