NO. FAULT LED 1 LED 2 LED 3 LED 4 LED 5 LED 6 LED 7 POSSIBLE SOLUTION 48 INTERNAL FAULT
  
RED Replace the control unit. Contact reseller/distributor.
49 INTERNAL FAULT
  
RED Replace the control unit. Contact reseller/distributor.
50 IGNITION FEEDBACK
   
RED The system detected voltage at terminal 16 at the incorrect time, or no voltage.
Check cabling and ensure sufcient earthing.
51 PILOT FEEDBACK
  
RED The system detected voltage at terminal 17 at the incorrect time, or no voltage.
Check cabling and ensure sufcient earthing.
52 MAINP FEEDBACK
   
RED The system detected voltage at terminal 19 at the incorrect time, or no voltage.
Check cabling and ensure sufcient earthing.
53 WAITING TIME FEEDBACK LIMIT
EXCEEDED
   
RED Loss of feedback from the damper motor for more than 10 minutes. Check the
cabling. Check the damper motor.
54 MAIND FEEDBACK
    
RED The system detected voltage at terminal 18 at the incorrect time, or no voltage.
Check cabling and ensure sufcient earthing.
55 DIAGNOSTICS INTERRUPTED
  
RED Replace the control unit. Contact reseller/distributor.
56 UV FALSE FLAME
   
RED False ame detected prior to ignition. Check the cabling. Check the ame detector.
Ensure sufcient earthing.
57 IONISATION FALSE FLAME
   
RED False ame detected prior to ignition. Check the cabling. Check the ame detector.
Ensure sufcient earthing.
58 OPEN FEEDBACK READING
    
RED The system detected voltage at terminal 8 at the incorrect time, or no voltage.
Check cabling and ensure sufcient earthing.
59 ADJACENT POLE SHORT-CIRCUIT
   
RED Replace the control unit. Contact reseller/distributor.
60 LOCAL RESET
     
RED The local reset button has been pressed in for more than 10 seconds, or the reset
button is stuck.
61 FUEL VALVE OPEN
   
RED Fuel valve open at incorrect time.
62 STRONG UV FLAME
    
RED
Flame detector too close to the ame. Increase the distance between the ame detector and the ame.
63 INTERNAL FAULT

RED Replace the control unit. Contact reseller/distributor.
