Bentone B 70-3 - 2 Technical Data B 70-3; Dimensions

7 Bentone
2. Technical data B 70-3
The burner is intended for:
• Light oil, B10 heating oil/biofuel blend (as defined in DIN V51603-6)
and is used for:
• Water heating generators
• Hot air generators
2.1 Dimensions
Dimensions are in mm
* Min. recommended distance to floor.
**A Ø B Ø C D E F G H *I
B 70-3
324 220 205 730 408 504 420 830 200
B 70-3
624 220 205 730 408 504 420 830 200
165 205 93
G
H
A D
Ø B
Ø C
E
F
*I
