Bentone B 70-3 - Configuration Level Conf; Controller Cntr; Generator Pro

52
Bentone
20. 9 Configuration level „ConF“
Linearization
0 Linear 10 Thermocouple type U
1 Pt100 11 Thermocouple type L
2 Pt500 12 Thermocouple type K
3 Pt1000 13 Thermocouple type S
4 KTY11-6 14 Thermocouple type R
5 Thermocouple type C 15 Thermocouple type B
6 Thermocouple type D 16 Thermocouple type N
7 Thermocouple type E 17 Thermocouple W3Re-W26Re
8 Thermocouple type T 18 customized linearization
9 Thermocouple type J
20.1 Controller „Cntr“
20.2 Generator „Pro“
9.3 Generator “Pro”
Parameter Symbol Value range
Function Fnct 0 Fixed-setpoint controller
1 Ramp function
2 Program controller
3 Program generator
4 Hot-channel controller
Factory settings are shown bold.
r In12 Analog input 1 and 2 general r
Parameter Symbol Value range
Temperature unit Unit 0 ... 1 (0=°C, 1=°F)
Sampling cycle time CycL 0 ... 3 (0=50 ms; 1=90 ms; 2=150 ms;
3=250 ms)
Factory settings are shown bold.
Parameter Symbol Value range
Controller type CtyP 0 no function
1 Two-state controller
2, 3 Three-state, modulating controller
4 Continuous controller
Control action CAct 0 ... 1
(0=direct (cooling); 1=inverse (heating))
Factory settings are shown bold.
