2.4 Model BF1 N1V 56-14/BF1 N1 56-14
2.4.1 Burner output
1,3 - 5,1 kg/h
15 - 60 kW
ø56
5,5–6,5
2,0–3,0 -05–0,5
ø61,5
ø14
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
10 15 20 25 30 35 40 45 50 55 60 65
Boiler overpressure, mbar
Burner output, kW
!
Scale value applies to 0 mbar furnace pressure.
Length of blast tube Protrusion from flange, measurement B
Flange
1 2
131 114 98
