Bentone BF1
General
Filter
6.1.2 Replacement of pump fi lter
Removal and installation
1. Close the oil supply to the burner
2. Loosen the pump cover’s screws.
3. Remove the fi lter and gasket
4. Mount new gasket and fi lter
5. Refi t the cover
6. Open the oil supply
7. Start the burner and check seals and combustion
!
Use caution when operating the burner, surfaces
may be hot.
!
When servicing oil bearing components, check for
oil leakage when the burner is commissioned after
servicing.
6.1.3 Check oil line seals
Once the burner has been installed and commissioned, the seals of the
various coupling elements should be checked (A).
When a leak is detected, it is usually suffi cient to tighten the coupling
element that is leaking.
Gasket
