Bentone BF1 - Modell BF1 R 69-16;BF1 RV 69-16; Burner Output; Basic Settings

13 Bentone BF1
General
ø89
!
Scale value applies to 0 mbar furnace pressure.
2.6 Modell BF1 R 69-16/BF1 RV 69-16
6,0–7,0
1,8–2,2
1,2–1,6
ø72,8
ø16
2.6.1 Burner output
1,3 - 5,5 kg/h
15 - 65 kW
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
10 15 20 25 30 35 40 45 50 55 60 65 70
0,0
2,0
4,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
15 2 0 25 3 0 35 4 0 4 5 5 0 5 5 60 6 5
Boiler overpressure, mbar
Burner output, kW Burner output, kW
2.6.2 Basic settings
Nozzle assembly
Air settings
Scale
Length of blast tube Protrusion from flange, measurement B
Flange
1 2
131 114 98
